FMS 1:7 Ford Bronco RTR EB Brushless 4WD

Description

FMS 1/7 Ford Bronco U4 Funhaver 24 RTR

De Ford Bronco RTR EB is an officially licensed 1/7 short course truck, developed in collaboration with Ford en RTR VehiclesInspired by the full-size Bronco that dominates Ultra4 racing, this model combines brutal power, scale-realistic detailing, and uncompromising off-road performance. From desert trails to rocky trails, this Bronco brings the thrill of extreme off-road racing right to your hands.

Official RTR Design

Built by the RTR Off-Road Team Created by Vaughn Gittin Jr. and Loren Healy, the Bronco RTR EB is based on the iconic 4400 Ultra4 Bronco. This RC truck embodies pure off-road innovation and is designed without limitations—built to push the boundaries.

Scale-realistic details

• 1,5mm thick polycarbonate body with metallic paint

• Aggressive roll cage, racing-style bumper and wide fenders

• Fully detailed interior

• Officially Licensed Nitto Trail Grappler tires

• Quick-release body clips for fast battery changes

Extreme off-road capability

• Brushless power: Hobbywing 4274 1600KV motor + 150A waterproof ESC

• Up to 80 km/h with 6S LiPo – or 4S setup for technical control

• Independent front suspension + rigid rear axle

• 3 oil-filled metal differentials (front, middle, back)

• 8 aluminum oil-filled shock absorbers for ultimate stability

• 60KG high-torque steering servo with metal gears

• Gyro-assisted transmitter for maximum control at high speeds

Durable & robust chassis

The Ford Bronco RTR EB rides on a CNC-machined aluminum chassis with reinforced metal components, including:

• Engine mount, differential housing & steering plate

• Aluminum shock absorbers

• Reinforced suspension parts and drive shafts

• Waterproof and dustproof electronics, with sealed receiver box

Lighting system

The truck comes standard with a fully working light set:

• Powerful headlights

• Roof lights

• Rear lights with different positions
  Perfect for night rides or realistic scale presentation.

Specifications

• Scale: 1/7

• Height: 650 mm

• Width: 350 mm

• Height: 273 mm

• Wheelbase: 425 mm

• Ground clearance: 45 mm

• Weight 7,5 kg

• Engine: Hobbywing 4274 1600KV brushless

• ESC: 150A waterproof brushless

• Servant: 60KG metal gear servo

• Tyres: Nitto Trail Grappler 146x55mm

• Wheels: 86×61×40 mm, 17 mm hex

• Drivetrain: 4WD with 3 diffs (front, center, rear)

• Max. speed: approx. 80 km/h (on 6S)

• Governance scope: approx. 200 m

• Recommended battery: 4–6S LiPo with EC5 connector

Box contents

• 1× Ford Bronco RTR EB 1/7

• 1× 2,4GHz transmitter & receiver (gyro-supported, installed)

• 1× Hobbywing 4274 1600KV brushless motor (installed)

• 1× 150A waterproof brushless ESC (installed)

• 1× Manual

Required to complete

• 4x AA batteries for the transmitter

• 4–6S LiPo battery (or 2× 2S/3S packs)

• LiPo charger
